F722 Flight controller + BLS60A 4in1 ESC

Description

F722 Flight controller + BLS60A 4in1 ESC

(Model): F722 Flight Controller

(MCU) STM32F722RET6

(IMU) ICM-42688

(OSD): AT7456E

(Baro) SPL06-001

(Blackbox): 16MB

(Input voltage): 3-8S Lipo(11.4-36V)

5V-BEC: 5V/3A ±0.1V

10V-BEC: 10V/3A(USER1)

IO2: USER2

(Receiver): ELRS(CRSF), TBS(CRSF), SBUS.IBUS.DSM2.DSMX

UART: UART1/2/3/4/5/6

(Size): 36*36MM

(Mounting Hole) 30.5*30.5*4MM

(Weight) 8.8g

Firmware: AXISFLYINGF7PRO BF/INAV

60A 4in1 ESC HV 2-6S

Size: 41 * 39 * 5mm

Aperture: 30.5 * 30.5mm (after installing the shock absorber ball, the aperture is 3mm)

Firmware: BLHELI-S

Weight: 15g

Input voltage: LIPO 2-6S

Continuous current: 60A

Maximum current: 65A (10 seconds)

Processor: EF8BB21

Drive signal support: DShot150-300-600/Multishot/Oneshot/PMW

Current sensor: supports
