Product Description

Skyroid UVC OTG Dual Antenna 5.8G FPV Receiver black

• Come with micro usb to micro usb and micro usb to usb type-c. Compatible with many Snapdragon Android phones.
• Frequency Range: 5645-5945, working Current: 200mA/S, channel: 150CH
• Antenna Impedance: 50Ω, antenna Gain: 5dbi
• Size: 61mm*33mm*0.9mm, weight: about 50

Skyroid UVC OTG Dual Antenna

Features:

1.150CH 5.8Ghz analog signal, 1500 scans cover all bands.

2.Resolution 640*480 30fps.

3.Can display frequency spectrum, to check the signal strength of antenna or transmitter.

4.Support dual display on smartphone, can be used as VR goggles.

5.Please calibrate it in open area, and keep away from transmitter more than 30m. Long press the menu button and power on receiver, enter into calibration mode.

Specifications:

Material: Plastic

Color: Black, White(Optional)

Frequency: 5645MHz~5945MHz

Resolution: 640*480 30fps

Working Current: USB 5V 190mA

Connector: RP-SMA

Working Temp.: -10°~65°

Size: 59x40x11mm/2.30×1.56×0.43in

Weight: 29g/1.02ozPC:

1.Use usb cable to connect it with PC.

2.XP: open the camera;WIN7: install AMCP camera software;WIN10: open camera. Or MP ground station.

3.After it power on, press the menu button for 3 seconds, it will self-search frequency and lock the strongest signal.

AV:

1.Use 4P cable (should DIY by player), 5V power input.

2.After it power on, press the menu button for 3 seconds, it will self-search frequency and lock the strongest signal.

Package Information:

Size: 110x75x25mm/4.29×2.93×0.98in

Weight: 84g/2.94oz

General Box Package

Note:

1.Do not support IOS system.

2.Some smartphones should open the otg function before use.

3.Some players have complained that it has the issue of flicker or short distance. After testing in open area, the reason has been found to be its high scanning accuracy, that the transmitted frequency is reflected by wall indoors and make the real frequency detected by receiver higher than it should be. So it is quite important to operate it in an open area and keep the receiver and transmitter more than 30m.

Package Included 1 in Quantity:

15.8Ghz 150ch Receiver

OTG Cable

Type-C cable

Antenn

Skyroid UVC OTG Dual Antenna

Caution:

• Storage Area temperature: Don’t put it beside the high temperature condition or the temperature is over 70 ° C.
• Keep away from kids that they can not get it.
• Flammable: Don’t throw it into fire.
• Don’t throw it into water.
• For safety, we recommend that you use the Motor to fly drones with Propeller.

FAQ

what is the purpose of Skyroid UVC OTG Dual Antenna 5.8G FPV Receiver black in Drones, Planes or RC Cars?

Answer: Skyroid UVC OTG Dual Antenna 5.8G FPV Receiver black turn any Android smartphone into a portable FPV monitor with this handy 5.8GHz receiver.
